STC4230vbl系列汽车成套机床 |
| |
|
| >> STC4230vbl系列Product Preview Keys：
Hits：4172 |
This lathe is special purpose machine for machining front & rear brake shoe used on automobile industry. Features. Single spindle, symmetrical-double-turrets and line-up tooling are available. Tool holders with high rigidity are made by ourselves according to actual situation of workpiece. All key components are imported form foreign well-known builders so that high reliability, big torque and high rigidity can be achieved. Fanuc 0i-Mate, AC main drive and AC feed servo motor are adopted. Special purpose clampers are available for clamping two workpieces simultaneously. With aid of double-turret structure, end surface and circular surface of workpiece can be machined at one time. |
|
| >> STC4230vbl系列Technical parameters |
|
Cutting Capacity
|
Max. Swing over Bed
|
-
|
|
Max. Turning Diameter
|
420mm
|
|
Max. Turning Height
|
300mm
|
|
Spindle
|
Speed Range
|
50-1000r/min
|
|
Chuck diameter
|
12"
|
|
Spindle Nose
|
A28
|
|
Spindle Bearing diameter(front)
|
130mm
|
|
Spindle Max. torque
|
214Nm
|
|
X/Z Axis
|
Stroke of X Axis
|
80mm
|
|
Stroke of Z Axis
|
350mm
|
|
Rapid Speed of X Axis
|
8m/min
|
|
Rapid Speed of Z Axis
|
8m/min
|
|
Accuracy
|
Precision Machining
|
IT7mm
|
|
X/Z axis positioning accuracy
|
0.035/0.040mm
|
|
X/Z axis repetitive positioning accuracy
|
0.0075/0.015mm
|
|
Tooling
|
Mode of Tool Post
|
Pai knife
|
|
Size of Shank External cutting tool
|
25×25mm
|
|
Boring tool
|
-
|
|
Power Motors
|
Main Motor (Nomina/30min)
|
7.5Frequency Motor kW
|
|
Servo Motor of X Axis
|
1.0kW
|
|
Servo Motor of Z Axis
|
2.6kW
|
|
Motor of Cooling Pump
|
-
|
|
Overall Dimensions
|
L
|
2630mm
|
|
D
|
2300mm
|
|
H
|
2350mm
|
|
Net Weight
|
5500kg
|
|
