CW6163B/C
CW6263B/C
|
CW6180Q
CW6280Q
|
CW6193B/C
CW6293B/C
|
CW6180B/C
CW6280B/C
|
CW61100Q
CW62100Q
|
CW61110B/C
CW62110B/C
|
|
Max. swing diameter over bed
|
630mm
|
800mm
|
930mm
|
800mm
|
1000mm
|
1110mm
|
|
Max. swing diameter over carriage
|
350mm
|
520mm
|
650mm
|
480mm
|
680mm
|
800mm
|
|
Max. workpiece length
|
750,1500,2000,3000-15000mm
CW(93/80Q)SeriesNo 750 specifications
|
1500，3000，4000，5000-15000mm
|
|
Max. swing diameter and width in gap
|
800/300mm
|
970/300mm
|
1100/300mm
|
1000/310mm
|
1200/310mm
|
1300/310mm
|
|
Spindle bore and nose
|
φ104mm；D11(Bseries） φ130mm；D11(Cseries）
|
|
Taper in spindle nose and center
|
φ120mm(Bseries） φ140mm(Cseries）；Morse No.5
|
|
Steps and range of spindle speeds
|
18Species7.5-1000(Bseries）r/min
18Species8.5-800(Cseries）r/min
|
18Species 6-800（Bseries）r/min
18series 8.5-800（Cseries）r/min
|
18series 5.4-720 r/min
|
18series 4.8-640 r/min
|
|
Steps and range of longitudinal feeds
|
64series
0.05-24.3 mm/r
|
64series
0.06-24.3 mm/r
|
64series
0.05-24.3 mm/r
|
64series0.06-24.3 mm/r
|
64series0.05-24.3 mm/r
|
|
Range1:1
|
0.1-1.52 mm/r
|
|
Range 16:1
|
1.6-24.3 mm/r
|
|
Range of fine feed with change gears
|
0.05-0.76 mm/r
|
0.06-0.912 mm/r
|
|
Longitudinal and cross feed rate
|
1/2
|
|
Rapid speed of carriage
|
4000 mm/min
|
|
Pitch of leadscrew
|
12mm(Dukes）；1/2"（Englishmen）
|
|
Number, range of Metric thread
|
50species 1-240 mm（Another 14 non-standard thread）
|
|
Number, range of Whitworth thread
|
26species 14-1 t.p.i
|
|
Number, range of Module thread
|
53species 0.5-120 mm
|
|
Number, range of diametral thread
|
24species 28-1 DP
|
|
Max. cross travel of lower slide
|
315 mm
|
450 mm
|
500 mm
|
500 mm
|
500 mm
|
500 mm
|
|
Max. travel of top slide
|
200 mm
|
200 mm
|
200 mm
|
200 mm
|
200 mm
|
200 mm
|
|
Max. travel of quill of tailstock
|
250 mm
|
250 mm
|
250 mm
|
250 mm
|
250 mm
|
250 mm
|
|
Taper of quill of tailstock
|
Morse No.5
|
Morse No.5
|
Morse No.5
|
Morse No.5
|
Morse No.5
|
Morse No.5
|
|
Width and hardness of bed guideways
|
550RC52 mm
|
550RC52 mm
|
550RC52 mm
|
600RC52 mm
|
600RC52 mm
|
600RC52 mm
|
|
Main motor power
|
11 kW
|
11 kW
|
11kW
|
11or15 kW
|
11or15 kW
|
11or15 kW
|
|
Rapid motor power
|
1.1 kW
|
1.1 kW
|
1.1 kW
|
1.1 kW
|
1.1 kW
|
1.1 kW
|
|
Power of coolant pump motor
|
90 w
|
90w
|
90w
|
90w
|
90w
|
90w
|
|
Width and hight of machine Width and hight packing case
|
1380×1450×1720×1710
1380×1770/ (CW6180Q)
1440×1835/1800×2340(CW6193series）mm
|
1550×1630/1820×1800
1550×1790/ （CW61100Q）
1560×1900/1800×2520（CW61110series）mm
|
|
Machine length/
Packing case length
|
Max. length
of work-piece
|
750
|
2890/3440mm
|
|
|
|
|
|
|
1500
|
3690/4240mm
|
3700/ mm
|
3690/3900mm
|
3700/4150mm
|
3700/4150mm
|
3700/3900mm
|
|
2000
|
4070/
|
|
|
|
|
|
|
3000
|
5190/5740mm
|
5250/ mm
|
5190/5400mm
|
5250/5650mm
|
5250/5650mm
|
5250/5400mm
|
|
4000
|
6120/6640mm
|
6120/ mm
|
6100/6350mm
|
6250/6650mm
|
6250/6650mm
|
6250/6450mm
|
|
5000
|
7200/7750mm
|
7200/ mm
|
7200/7430mm
|
7250/8050mm
|
7250/8050mm
|
7250/7630mm
|
|
N.W/G.W of machine
|
Max. length of workpiece
|
750
|
3400/4400mm
|
|
|
|
|
|
|
1500
|
3700/4700mm
|
4300/ mm
|
4200/4950mm
|
4900/6000mm
|
4900/6000mm
|
5500/6350mm
|
|
2000
|
4200/ mm
|
|
|
|
|
|
|
3000
|
4700/5900mm
|
5300/ mm
|
5200/6250mm
|
5500/6900mm
|
5500/6900
|
6100/7250mm
|
|
4000
|
5800/7700mm
|
6400/ mm
|
6300/7500mm
|
6100/8000mm
|
6100/8000mm
|
6700/8150mm
|
|
5000
|
6800/8800mm
|
7400/ mm
|
7300/8700mm
|
6900/9000mm
|
6900/9000mm
|
7500/9200mm
|
|
Width of bed guideways
|
550 mm
|
550 mm
|
550 mm
|
600 mm
|
600 mm
|
600 mm
|
|
Max. weight of workpiece
|
2000 kg
|
2000 kg
|
2000 kg
|
2000 kg
|
2000 kg
|
2000 kg
|
