Distance between spindle center and bed guide-way
|
365mm
|
|
Distance between spindle center and feed rack
|
15mm
|
|
Distance between cutterheads(double feed racks)
|
410-1200/2000mm
|
|
Machining diameter range
|
φ50-φ160mm
|
|
Cutterhead diameter
|
φ125-φ200mm
|
|
Diameter of center hole drilling
|
3、4、5、6.3mm
|
|
Horizontal moving distance of headstock
|
220mm
|
|
Distance between milling spindle and drilling spindle
|
220mm
|
|
Speed range of milling spindle
|
160-500rpm
|
|
Speed range of drilling spindle
|
500-1000rpm
|
|
Main motor power
|
7.5kW
|
|
Hydraulic pump motor
|
3kW
|
|
Cooling pump motor
|
0.125kW
|
|
Machine dimension
|
3280×1900×1900mm
|
|
Machine weight(machine+hydravlic station)
|
8000+800=8800kg
|
