Max. diameter of crankshaft to be machined
|
φ120mm
|
|
Max. length of crankshaft to be machined
|
1200mm
|
|
Max. swing diameter of crankshaft to be machined
|
φ300mm
|
|
Diameter range of crankshaft oil hole to be machined
|
φ5-φ10mm
|
|
Max. travel of X-axis
|
1400mm
|
|
Max. travel of Z-axis
|
460mm
|
|
Positioning accuracy of X/Z-axis
|
0.012/0.01mm
|
|
Repeat positioning accuracy of X/Z-axis
|
0.01/0.007mm
|
|
Drilling head speed range
|
1000-5000rpm
|
|
Max. swivel angle of drilling head
|
±60°
|
|
Vertical travel of drilling head
|
100mm
|
|
Main motor power
|
3kW
|
|
High voltage cooling system
|
25L/min
|
|
|
80Bar
|
|
Machine power
|
25kW
|
|
Machine Dimension
|
4000×3600×2200mm
|
|
Machine weight
|
10000kg
|
